This product is controlled by high-performance intelligence mcu.
With high precision 0 V and - ? V detection
With constant flow output, protection of overcharge and short circuit, control of the maximum time, capacity and voltage.
With single electrical quantity detection technology, precision control and more convenient and intuitive single current display.
NI-MH batteries with different capacity and variety and the alkaline batteries are allowed to be charged in a mixed way.
With a high degree of integration and high stability.
With automatic trickle charge function.
Safety and reliability are guaranteed by means of failure recognition technology of high intelligence alkaline battery as well as identifiable technology which can identify the failed dry battery.
Use Directions
The rechargeable batteries are applicable to digital cameras, MP3, CD, MP4 and walkmans etc. after they are fully charged.
After the Nickel-hydrogen batteries are fully charged, the battery overcharge will not occur if the battery is still charged through the trickle charge or it is charged for a long time.
This product has a much better activation effect on the alkaline batteries for digital cameras, toy wagons, toy motor cars and other high current equipment(the working current is larger than 300mA), and can have a high activation frequency.
Because of the "Inertia Memory" feature of the alkaline battery, the alkaline battery which has been used in the original equipment is suggested to be used in the original equipment after it is activated by this products. In that case, it can have a better effect.
This product can not activate the failed alkaline battery. The alkaline batteries which are used for a long time in the remote controls, clocks and other low current equipment(The current is less than 200mA), is not suggested to be activated by this product after it is used up(namely failed).
Because of the diversity of the alkaline batteries made by different manufacturers, the cyclic activation frequency of this product differs which can reach as much as 80 times. It is suggested to use the fine quality alkaline battery in market so as to reach a better activation effect.
Function of the Indicator Light
Self-inspection: After it is connected to power supply, all the indicator lights go on, with the red and green lights shining alternatively for a second and then going out.
Charge indication of the nickel-hydrogen battery: When the battery is being charged, the corresponding indicator light is long red.
Activation indication of the alkaline battery: When the battery is activated, the corresponding indicator light shines alternatively between the red and green.
Advance activation indication of the alkaline battery: When the battery is activated, the corresponding indicator light is long red.
Full charge indication: The greed light shines long time.
Poor contact indication of the battery: The red light shines.
When the damaged battery is switched in, the system will not charge and the red light shines.
FAQ of Alkaline Battery Reactivate Charger
What is the "Inertia memory" properly of the alkaline battery?
A: The alkaline battery which has been used in the original equipment, should continued to be used in the original equipment after it is activated by this product, for the working current and voltage of the original equipment have made the internal chemical substance steady state. In other words, the alkaline battery has "remembered" the working current of the original equipment, which is called "Inertia memory" feature of the alkaline battery.
how to use the alkaline battery to complete many times of activation?
A: Because of the Inertia Memory feature of the alkaline battery, the alkaline battery should be activated immediately when the remaining electric energy is around 20% so as to avoid over-discharge which gives rise to failure of the battery. For example, if the flashlight with a new alkaline battery doesn't work after it is used for 8 hours, in order to obtain more effective activation times, the alkaline battery should be activated after it is used for 6 hours.
How long can the alkaline battery be used while activated?
A: According to results of making testing on Samsung S750 digital camera and Duracell battery for several times, it can be seen that:
A: Time for10 times of usage: 120% - 100% of the new battery
B: Time from the 11th to 15th: 100% - 85% of the new battery
C: Time from 16th to 30th: 85% - 40%
Can the alkaline battery and NI-MH battery be charged in hybrids and activated simultaneous?
A: Absolutely Ok. Because the self-adapting charge technology is adopted in this product for mixed charge of the high intelligence alkaline battery and NI-MH battery, any different varieties of battery in different combination can be identified exactly and automatically.
How to conserve the activated alkaline battery?
If the activated alkaline battery is to be stored, please do it after the electric energy is used up. Otherwise, leakage may occur. If the activated alkaline battery has been stored for a long time, the re-activation effect will be relatively poor.
Can the alkaline battery explode while being activated?
A: The principle of using this product is to revitalize and activate again the internal chemical substance of the battery but not to charge, as long as it is normally operated according to the instruction manual, the alkaline battery will absolutely not explode in the process of activation except it is artificially damaged.
Reason 1: We adopt the failure detection technology of the alkaline battery, it can automatically stop the activation before exploration of the battery so that exploration is avoided.
Reason 2: Each alkaline battery has safety gasvalve, so it will not explore.
Can the alkaline battery be activated after it is used up in the low current equipment such as the flashlight and clock?
A: When the flashlight doesn't go on, the battery will be discharged to a very low voltage as near as 0V, which is far below the 1.3V of reference voltage. The internal structure of the battery has been destroyed and the battery has lost effectiveness. It is similar to that good "doctor" can not save the "life" of a "died man" either, so the battery can not be activated again.
How to operate the alkaline battery to reach the better activation effect while it is being used in the flashlight, toy car or other equipment?
A: Because the equipment has no function of automatic shutdown, the battery will be discharged to a very low voltage when usage in the equipment is completed. It is less than 1.3V, which has destroyed the internal structure of the battery and the battery has lost effectiveness, so the battery should be activated before it doesn't fail, so that a better activation effect is reached, in other words, when the remaining electric energy of the battery is 20%.
Why is the activation effect of the alkaline battery used in the digital camera better than that of the alkaline battery in full use for the flashlight?
A: Because the automatic shutdown function of the digital camera, when the voltage of the battery at work is less than 1.3V, the digital camera will shutdown automatically so that the battery is not discharged to a very low voltage. Therefore, the battery gets protected. It reaches a better activation effect. The equipment like the flashlight or toy car has no automatic shut-down function, the battery will usage is completed. It is less than 1.3V, which has destroyed the internal structure of the battery. The battery has lost effectiveness and the activation effect is poor.
Why is the indicator light red while the alkaline battery is activated?(Normally, the red and green lights shine alternatively)
A: When the voltage is very low after the alkaline battery is switched in, Alkaline Battery Reactivate Charger automatically enters into an advance activation state. At this time, the red light shines. When the advance activation is completed, the normal activation state starts. The indicator light shines between the red and green. The two situations above are normal. It can be safely used.
Why can the alkaline battery be used for a shorter time after its activation is completed?
A: Failed alkaline batteries
B: Poor quality alkaline batteries
C: Alkaline batteries used for many times
How to deal with the leakage which happens in the process of activation?
A: Normally, leakage will not occur when the alkaline battery is activated. It is unnecessary to worry the leakage occurring when the battery is of poor quality, because this product is designed to be leakage-proof. Only wipe the leaked liquid clean and replace the battery by a new one. And then it can be normally used.
Why can some batteries not be activated or the activation effect is poor?
A: Because the internal chemical substance has been seriously exhausted and destroyed after its usage is completed in the low-current equipment like the clock, remote control and flashlight etc. it is similar to a ninety-year-old man can not obtain vitality of twenty-year-old young man even though he has the best diet, so the activation effect is relatively poor.
Why the voltage of the alkaline battery reduced a bit after its activation is completed?
A: Because the internal chemical reaction has not completely been stable when the activation of the alkaline battery is completed, the voltage of the battery will not go down after the internal chemical reaction is stable, when it is placed for some time after being taken from the charger. It is normal. The voltage of some rechargeable batteries such as nickel-hydrogen battery will also go down when they are fully charged and put for some time. The only difference is that the voltage of those batteries is reduced less.
Why does the indicator light indicate that the red and green lights shine alternatively when the nickel-hydrogen battery is being charged?
A: Normally the indicator light turns red when the nickel-hydrogen battery is being charged, if the red and green lights shine alternatively, it shows the battery has been fully charged for it has a high internal resistance. In that case, use up all the electric energy of the battery and then charge it. If the red and green lights remain shining alternatively, it shows the usage time of this battery is short or other words, the battery has been damaged, it is suggested not to use it again.
Now what brand of alkaline batteries in market has the better effect of usage when they are activated by this product?
A: Through repeated cyclic tests on this product(namely the alkaline battery activator), it is proved that all the alkaline battery(LR6 LR03) in present market can be used after activation. It is recommended to use Duracell alkaline battery for it will have a better effect.
Input: AC 100V - 240V 50/60Hz Max 100mA
NI-MH Out put: 1.4V - 1600mA 1 AA
1.4V - 800mA 1 AAA
Applicable for the capacity of battery 500mAh - 3500mAh
Caution: Risk of electric shock, dry location use only.
Warning
No taking apart allowed to avoid attack from the electricity
No charging for non-rechargeable batteries
