HDSLR System » HD LCD Monitor » Viltrox 5'' DC-50 Clip-on Color TFT LCD Monitor HDMI
Viltrox 5'' DC-50 Clip-on Color TFT LCD Monitor HDMI
Viltrox 5'' DC-50 Clip-on Color TFT LCD Monitor HDMI
JYC
Out of stock
Viltrox DC-50 Clip-on Color LCD Monitor with HDMI, AV Input
Description

This DC-50 monitor is a portable LCD monitor used with an interchangeable lens digital camera or an interchangeable lens digital HD video camera recorder with an HDMI terminal and live view mode together.

Viltrox DC-50 Clip-on LCD Monitor adopts with SHARP 5'' TFT high resolution LCD panel, loaded with pro-style features to help photo enthusiasts and videographers shoot high-quality HD video footage with their camera. The pixel magnification and peaking facility which ensure accurate focus confirming, give an enlarged pixel-perfect view of a selected portion of the full HD image.

Features:

Wide viewing angle LCD screen.

With peaking and pixel-by-pixel zoom function.

Can control the camera shutter, ensuring long-distance monitor.

The moveable range of the shoe adapter is about 90 degrees forwards or backwards and 180 degrees left or right. (But don't push too hard)

With sun shade, best choice to use outdoor under sunlight.

The monitor is light weight and easy to carry.

The monitor has standard 1/4'' thread hole, it can connect to your camera, magic arm, hot shoe stand....easily.


Panel Size: Approx. 5"
Resolution: 800×480 pixels
AC Adapter: 8V / 2A
Input Jack: HDMI: 2 / AV: 1 / DC IN Power Adapter Plug: 1 / USB Update Jack: 1
Headphone Output Jack: 3.5Φ
Camera Shutter Release Jack: 2.5Φ
Speaker: 1 (built-in)
Power: Work With One Chargeable Battery: FM500H, QM71D or QM91D (The batteries are not included)
Operating Temperature: 0℃~+40℃ / +32~+104℉
Storage Temperature: -20℃~+60℃ / -4~+140℉
Size: (WXHXD) Approx. 129×88.5×20mm/5.1×3.5×0.8''
Weight: Approx. 250g / 8.8 (oz)



Note:

The aspect ratio of the LCD panel of this unit is 15:9, so black stripes may appear above and below or on each side of movie images that have an aspect ratio of 16:9 and 4:3.

The setting functions of this unit only affect the image displayed on the LCD screen. They do not affect the actual recorded image.

When the peaking function is on, the image displayed on the LCD screen is only for checking the effect. The peaking function does not affect the actual recorded
image.
