The DOF F2-HDMI LCD monitor is lightweight, portable, and boasts a LED backlight display. It has a wide screen with the aspect ratio 16:9, a very user-friendly operation interface. It has a display screen that measures 1024*600 pixels and supports 1080P Full HD video signal, HDMI 1.4 and BNC video transmission. The monitor also provides AV/HDMI's signal input and output. You can enjoy a good monitoring effect as well as that of broadcasting quality.
High brightness: The display screen's brightness is up to 400cd/㎡. Viewing angle is 170°. Pixels are 1024*600. All these elements make the monitor's image remain clear, full sensory and richness of layering regardless of using it indoor or outdoor and allow photographers to see a more realistic source image.
Focus assist: When photographers adopt the manual focus mode, the image can be displayed through red crest value or white crest value that you can choose. According to observing whether the image edge displays the color of corresponding crest value, you can judge whether the image is in focus or not.
Center mark and marker line: Multiple aspect ratio marked boxes([off](default),[16:9],[15:9]，[14:9]，[13:9]，[4:3]，[2.85:1]，[1.85:1]), caption box, shooting tag line and cross central line are equipped with in the monitor. These elements allow you to compose your image more quickly and accurately.
Color measurement: The monitor can measure colors including red, green, blue, black and white to revivify real color of the object being imaged from the display screen.
Broadcasting safety frames: Broadcasting safety frames at different ratios can prevent scanning from overflowing to result in the image being cut off unnecessarily. This function is mainly used for safety confirmation and reminding during the process of composition of an image.
Image freezing and zooming in dot by dot: It can freeze and magnify the video signals, so you can look over local details. Under this condition, you still see the image with 1080 pixels.
Product Model: F2-HDMI LCD monitor
Screen Size: 7"(diagonal)
Display Area: 155mm(H) * 87mm(V)
Aspect Ratio: 16:9 / 4:3 Selectable
Pixels: 1024 * 3(RGB) * 600
Selectable Color Depth: 16.7M
Brightness: 400cd/㎡
Contrast Ratio: 900:1
Viewing Angle: 170°
Dot Pitch: 0.1506mm(H) * 0.1432mm(V)
Compatible Input Formats: Composite-PAL/NTSC; HDMI-480i/p,576i/p,720p,1080i/p
Audio Input/Output: BNC Female (8Ω)
HDMI Input/Output: HDMI(Type A)Female, HDMI(Type C)Male
AV Input/Output: BNC Female
Operating Voltage: DC 6.0-16.8V
Working Temperature: -20°C to 70°C
Max Input: 1Amp, 6W
Item Size: 17.5 * 13 * 3.2cm / 6.9 * 5.1 * 1.3in(L * W * H)
Item Weight: 518g / 18.3oz
Package Size: 22.8 * 15.3 * 6.8cm / 9.0 * 6.0 * 2.7in (L * W * H)
Package Weight: 698g / 24.65oz
Package List：
1 * F2 7" LCD monitor-HDMI
1 * HDMI cable
1 * PVC sunshade
3 * Sunshade fixing screw
1 * Universal rotating head
