The Audio-Technica Pro 88W is a cost effective VHF wireless microphone system intended for video application. The system includes a belt-pack transmitter, camera mountable receiver and MT830mW omni-directional lavalier microphone. The receiver features 2 user selectable VHF frequencies for added flexibility when experiencing RF interference.
Provisions for headphone monitoring are provided, ear-phones are included. The belt-pack transmitter features a 1/8" mini microphone input, the optional CP8306 cable will adapt balanced XLR terminated microphones to the transmitter. Both transmitter and receiver feature a durable metal housing and will operate up to 8 hours on 9 Volt alkaline batteries.
Selectable Frequencies
The Pro 88 receiver features 2 user selectable VHF frequencies, providing the flexibility needed when experiencing RF interference.
Monitoring Capability
The receiver features real-time audio monitoring and the monitor ear-phone is included.
Durable Construction
Both transmitter and receiver feature durable plastic construction, able to withstand the rigors of use on location or on the road.
MT830mW Microphone
The MT830mW lavalier microphone features an omni-directional polar pattern. The omni-directional pattern provides a generous pick up with even signal response at the direct and off-axis sections of the capsule.
System
Type of System VHF Single Frequency Portable
RF Carrier Frequency Range 169.445 - 180.600 MHz
Approx. Working Range 100' normal, 300' Optimum
Overall Frequency Response not specified by manufacturer
Signal-to-Noise Ratio not specified by manufacturer
# Of Channels 2 Switchable Frequencies - T24 / 169.505 & 170.305MHz
# Of Simultaneous Systems not specified by manufacturer
Receiver
Type of Receiver Camera Mountable VHF - FM Super-heterodyne
Type of Outputs 1/8" (3.5mm) Mini unbalanced
Headphone Monitoring Yes, Headphone included
Power Requirements DC Input: 9 Volt DC (center - positive)
Battery: 9 Volt alkaline (not included)
Battery Type/Approx. Life 8 hours nominal
Mounting Options Touch Fastener
Antenna Type External
Dimensions 4.09 x 2.44 x .94 (104 x 62 x 24mm) (HxWxD)
Transmitter
Type of Transmitter Body-Pack - Frequency Modulation
Type of Input Connector 1/8" (3.5mm) Mini unbalanced
Type of Microphone MT830mW
Polar Pattern Omni-directional
Interchangeable Mic Heads AT829mW cardioid lavalier & PRO 8HEmW hyper-cardioid head-worn available, CP8306 cable allows integration with balanced XLR microphones.
Battery Type/Approx. Life Battery: 9 Volt alkaline
Mute Switch No
Level Control No
Antenna Type External
Display not specified by manufacturer
Dimensions 4.09 x 2.44 x 0.94" (104.0 x 62.0 x 24.0mm) (HxWxD)
Weight 2.8 oz (80 grams)
