This ENG set offers a great amount of flexibility for portable recording indoors or outdoors. Its SKP 100 G3 plug-on transmitter transforms XLR equipped devices (such as microphones and mixing consoles) into wireless devices by simply plugging the unit in. The bodypack transmitter, as well as the plug on, can by synced up to the receiver with the simple push of a button. A very small high-quality directional clip-on microphone completes this set. - See more at: http://www.sennheiser.ca/live/senn/produit/en/1132/#sthash.dXpqT4F3.dpuf
Sturdy metal housing (transmitter and receiver)
42 MHz bandwidth: 1680 tunable UHF frequencies for interference-free reception
Enhanced frequency bank system with up to 12 compatible frequencies
Adaptive-diversity reception for high reception quality
Pilot tone squelch for eliminating RF interference when transmitter is turned off
Automatic frequency scan feature searches for available frequencies
Enhanced AF frequency range
Increased range for audio sensitivity
Wireless synchronization of transmitters via infrared interface
User-friendly menu operation with more control options
Illuminated graphic display (transmitter and receiver)
Auto-Lock function avoids accidental changing of settings
HDX compander for crystal-clear sound
Transmitter and receiver feature battery indicatation in 4 steps
Programmable Mute function
Contacts for recharging BA 2015 accupack directly in SK 100 G3 or EK 100 G3
Wide range of accessories adapts the system to any requirement
|
Transmission/receiving frequencies |
1680 |
|
Presets |
12 |
|
Switching bandwidth |
42 MHz |
|
Peak deviation |
+/- 48 kHz |
|
Compander |
HDX |
|
Frequency response (microphone) |
80 - 18000 Hz |
|
Signal-to-noise ratio |
> 110 dB(A) |
|
THD, total harmonic distortion |
< 0,9 % |
|
In compliance with |
ETS 300422 , ETS 300445 , CE , FCC |
|
Audio-XLR connector |
3,5 mmjack |
|
Audio output level (unbalanced) |
+10 dBu max |
|
Dimensions (Receiver) |
82 x 64 x 24 mm |
|
Weight (Receiver) |
~ 160 g |
|
RF output power |
30 mW |
|
Operating time (transmitter) |
> 8 h |
|
Input voltage range |
Mic/Line, 1,8V/3,0V (SK100G2), Mic, 1,2V (SKP100G2) |
|
Dimensions (Transmitter) |
82 x 64 x 24 mm (SK100 G2), 105x43x43mm (SKP100G2) |
|
Weight (Transmitter) |
~ 160 g (SK100G2), 195g (SKP100G2) |
|
Transducer; Microphone type |
elektret |
|
AF sensitivity |
20 mV/Pa |
|
Sound pressure level (SPL) |
130 dB(SPL) max. |
|
Pick-up pattern |
omni- directional |
|
