The Azden WHD-Pro Audio Kit contains an Azden SMX-10 Stereo Shotgun Microphone and an Azden WLX-Pro On-Camera VHF Wireless System. This Audio Kit allow DSLR camera owner to get quality external audio input. Now you can record in stereo directly with Azden's SMX-10. The 177 mm long, dual uni-directional, electret-condenser mic is powered by a single "AAA" battery (not included) and features a built-in cable with a 3.5 mm stereo mini-plug. Comes with a windscreen and camera hot-shoe mount. The complete system which includes the WL/T-PRO a belt-pack transmitter (WM-PRO) with electret condenser lavalier microphone (EX-503) and the WR-PRO receiver which comes with both shoe-mount and hook and loop fastener. All receivers and transmitters in the "PRO" Series are on the same 2 frequencies any time.
Wireless Microphone Features :
A complete system which includes the WL/T-PRO a belt-pack transmitter (WM-PRO) with electret condenser lavalier microphone (EX-503) and the WR-PRO receiver which comes with both shoe-mount and hook and loop fastener. All receivers and transmitters in the "PRO" Series are on the same 2 frequencies (169.445MHz and 170.245MHz).
• Transmits Audio Up to 100 Feet Away
• Body-pack Transmitter with Clip-on Lapel Microphone
• Portable Camera-mount Receiver with Pivoting Antenna
• 2 Selectable Frequencies for Clear Reception
Receiver Technical Specs :
Receiver type: Double superheterodyne
Sensitivity: 2mV @ S/N of 40dB
Battery: 1-9V Alkaline
Power consumption: 25mA
Monitor output: 1V @ 30W, Modulation frequency: 1kHz, Deviation: +/-7kHz
Mic output: 8mV w/10KW load, Modulation frequency: 1kHz, Deviation: +/-7kHz
Mic output impedance: 300W
Dimensions: 86(h) x 60(w) x 21.5(d) mm (3.3” x 2.4” x 0.85”)
Weight w/battery: 128g (4.5oz)
Transmitter Technical Specs :
Modulation system: FM
Sensitivity: 94dB SPL @ +/- 2.5KHz deviation
Battery: 1-9V
Power consumption: 30mA
Dimensions: 86(h) x 60(w) x 21.5(d) mm (3.3" x 2.4" x 0.85")
Weight: 98g (3.4oz)
Directional Stereo Microphone Features :
Now you can record in stereo directly with Azden's SMX-10. The 177 mm long, dual uni-directional, electret-condensor mic is powered by a single "AAA" battery (not included) and features a built-in cable with a 3.5 mm stereo mini-plug. Comes with a windscreen and camera hot-shoe mount.
• Reduces Side and Background Sounds
• Removable Foam Windscreen
• Shock-mount Microphone Holder with Shoe
• Switchable LF Filter for Clear Sound
Technical Specs :
Type : Stereo Electret Condenser
Frequency Response : 100-18,000Hz
Sensitivity : -40dB @1kHz (1V/Pa)
Output Impedance : 1.5 k ohm @ 1kHz
Signal-to-Noise Ratio : 60dB (1kHz @ 1Pa)
Dynamic Range : 66dB
Power Supply : 1.5VDC ("AAA" size battery) - not included
Max. SPL : 100dB
Battery Current Drain : 0.5mA
Battery Life : 400 hours with Alkiline battery
Weight w/o battery : 52g
Dimensions : 177mm long - 18.2mm diameter
Output cable : attached with 3.5mm plug
Supplied Accessories : Camera hot-shoe mic holder, windscreen
