All-new 12.3 effective megapixel Nikon DX-format CMOS image sensor with integrated A/D converter and the increased bit precision of selectable 14-bit NEF (RAW) output
Incorporates Nikon's original EXPEED digital image processing concept
Nikon's original Scene Recognition System greatly improves autofocus, auto exposure and auto white balance performance
New 51-point autofocus system features 15 cross-type sensors that maximize the potential of lenses with apertures as small as f/5.6
Viewfinder with approx.100% frame coverage and large approx.0.94 magnification (50mm f/1.4 lens at infinity, –1.0 m-1)
Rapid 8 fps*1 or 6 fps*2 continuous shooting for up to 100 shots*3*4
New Picture Control System for image finishing optimized to match individual preferences
Quick response of 0.13 sec. power-up and 0.045 sec. shutter release time lag*5
Two liveview modes enable shooting while confirming subjects in the LCD monitor
Magnesium alloy body for light weight and rugged durability
3-inch LCD with 920,000-dot (VGA) resolution and a 170° ultra-wide viewing angle
Active D-Lighting optimizes tone reproduction in both shadows and highlights
Shutter speeds ranging from 1/8,000 to 30 s for full creative control
Optional Multi-Power Battery Pack MB-D10 extends shooting capability, enhances stability, and provides the further shooting potential of added controls
Built-in Speedlight with i-TTL flash control and full support for Nikon's Creative Lighting System
Support for the Wireless Transmitter WT-4 (optional) enables direct cable-free image transfer to a compatible computer
Includes Nikon’s Software Suite software for easy control over image adjustment and management
Supported by Nikon Capture NX software (optional), to explore the extensive potential of NEF (Nikon Electronic Format)
Precision engineered to deliver new professional-level functionality, performance and reliability, the Nikon D300 combines innovative Nikon technologies with advanced new features to optimize all aspects of camera performance and form the ideal blend of Nikon DX-format performance.
Type of Camera
Single-lens reflex digital camera
Effective Pixels
12.3 million
Image Sensor
CMOS sensor, 23.6 x 15.8 mm; total pixels: 13.1 million; Nikon DX format
Image Size (pixels)
4,288 x 2,848 [L], 3,216 x 2,136 [M], 2,144 x 1,424 [S]
Dust-reduction System
Clean image sensor, image dust-off data acquisition (Capture NX required)
Sensitivity
ISO 200 to 3200 in steps of 1/3, 1/2 or 1 EV with additional settings of approx. 0.3, 0.5, 0.7 and 1 EV (ISO 100 equivalent) under ISO 200 and approx. 0.3, 0.5, 0.7 and 1 EV (ISO 6400 equivalent) over ISO 3200
File System
Compliant with DCF 2.0, DPOF and Exif 2.21
Storage System
NEF 12-bit or 14-bit (uncompressed, lossless compressed or compressed RAW)
TIFF (RGB)
JPEG: JPEG baseline-compliant
Storage Media
CompactFlash (CF) Card (Type I and II, UDMA compliant), Microdrive
Release Modes
1) Single frame [S] mode 2) Continuous low speed [CL] mode: 1 to 7*1 frames per second 3) Continuous high-speed [CH] mode: 8 frames per second*1, 6 frames per second*2 4) Live View [LV] mode 5) Self-timer [] mode 6) Mirror-up [Mup] mode
*1. When using AC Adaptor EH-5a/EH-5 or Multi-Power Battery Pack MB-D10 with batteries other than Rechargeable Li-ion Battery EN-EL3e
*2. When using Rechargeable Li-ion Battery EN-EL3e
(When shooting in Continuous-servo AF (C), Shutter-Priority Auto [S] or Manual [M] exposure modes, at a shutter speed of 1/250 s or faster with other settings at default)
White Balance
Auto (TTL white balance with 1,005-pixel RGB sensor), seven manual modes with fine-tuning, color temperature setting, white balance bracketing possible (2 to 9 frames in increments 1~3)
Live View
Hand-held mode, Tripod mode
LCD Monitor
3-in., approx. 920,000-dot (VGA), 170-degree wide viewing angle, 100% frame coverage, low-temperature polysilicon TFT LCD with brightness adjustment
Playback Function
1) Full frame 2) Thumbnail (4 or 9 segments) 3) Zoom 4) Slideshow 5) RGB histogram indication 6) Shooting data 7) Highlight point display 8) Auto image rotation
Delete Function
Card format, All photographs delete, Selected photographs delete
Video Output
NTSC or PAL; simultaneous playback from both the video output and on the LCD monitor available
HDMI Output
Supports HDMI version 1.3a; Type A connector is provided as HDMI output terminal; simultaneous playback from both the HDMI output terminal and on the LCD monitor not available
Interface
Hi-Speed USB
Text Input
Up to 36 characters of alphanumeric text input available with LCD monitor and multi-selector; stored in Exif header
Lens Mount
Nikon F Mount with AF coupling and AF contacts
Compatible Lenses
1) DX AF NIKKOR: All functions possible
2) D-/G-type AF NIKKOR (excluding IX NIKKOR lenses): All functions possible (excluding PC Micro- NIKKOR)
3) AF NIKKOR other than D-/G-type (excluding lenses for F3AF): All functions except 3D-Color Matrix Metering II possible
4) AI-P NIKKOR: All functions supported except 3D color matrix metering II and autofocus
5) Non-CPU AI NIKKOR: Can be used in exposure modes A and M; electronic range finder can be used if maximum aperture is f/5.6 or faster; Color Matrix Metering and aperture value display supported if user provides lens data
Picture Angle
Equivalent in 35mm [135] format is approx. 1.5 times lens focal length
Viewfinder
SLR-type with fixed eye-level pentaprism; built-in diopter adjustment (-2.0 to +1.0 m-1)
Eyepoint
19.5 mm (-1.0 m-1)
Focusing Screen
Type-B BriteView Clear Matte screen Mark II with superimposed focus brackets and On-Demand grid lines
Viewfinder Frame Coverage
Approx. 100% (vertical and horizontal)
Viewfinder Magnification
Approx. 0.94x with 50mm lens at infinity; -1.0 m-1
Autofocus
Nikon Multi-CAM 3500DX autofocus module with TTL phase detection, fine-tuning, 51 focus points (including 15 cross-type sensors) and AF-assist illuminator (range approx. 0.5 to 3 m / 1 ft. 8 in. to 9 ft. 10 in.)
Focal plane contrast [in Live View (Tripod) mode]
Lens Servo
Single-servo AF (S); continuous-servo AF (C); manual (M); predictive focus tracking automatically activated according to subject status in continuous-servo AF
Focus Point
Single AF point can be selected from 51 or 11 focus points
Live View (Tripod mode): Contrast AF on a desired point within entire frame
AF Area Mode
1) Single point AF 2) Dynamic Area AF [9 points, 21 points, 51 points, 51 points (3D-tracking)] 3) Automatic-area AF
Focus Lock
Focus can be locked by pressing shutter-release button halfway (single-servo AF) or by pressing AE-L/AF-L button
Exposure Metering System
TTL full-aperture exposure metering using 1005-pixel RGB sensor
1) 3D Color Matrix Metering II (type G and D lenses); color matrix metering II (other CPU lenses); color matrix metering (non-CPU lenses if user provides lens data; metering performed)
2) Center-weighted: Weight of 75% given to 6, 8, 10, or 13 mm dia. circle in center of frame or weighting based on average of entire frame (8 mm circle when non-CPU lens is used)
3) Spot: Meters approx. 3 mm dia. circle (about 2.0% of frame) centered on selected focus point (on center focus point when non-CPU lens is used)
Exposure Metering Range
1) 0 to 20 EV (3D Color Matrix or center-weighted metering) 2) 2 to 20 EV (spot metering) (ISO 100, f/1.4 lens, 20°C)
Exposure Meter Coupling
Combined CPU and AI
Exposure Modes
1) Programmed Auto [P] with flexible program 2) Shutter-Priority Auto [S] 3) Aperture Priority Auto [A] 4) Manual [M]
Exposure Compensation
±5 EV in increments of 1/3, 1/2 or 1 EV
Auto Exposure Lock
Detected exposure value locked by pressing AE-L/AF-L button
Auto Exposure Bracketing
Exposure and/or flash bracketing (2 to 9 exposures in increments of 1/3, 1/2, 2/3 or 1 EV)
Picture Control System
Four setting options: Standard, Neutral, Vivid, Monochrome; each option can be adjusted
Shutter
Electronically-controlled vertical-travel focal plane shutter, 1/8,000 to 30 s in steps of 1/3, 1/2 or 1 EV, Bulb
Sync Contact
X=1/250 s; flash synchronization at up to 1/320 s (FP) adjustable with Built-in Speedlight or optional Speedlight (will reduce GN)
Flash Control
1) TTL: TTL flash control by 1,005-pixel RGB sensor
Built-in Speedlight, SB-800, SB-600 or SB-400: i-TTL balanced fill-flash and standard i-TTL flash
2) AA (Auto Aperture-type) flash: Available with SB-800 used with CPU lens
3) Non-TTL Auto: Available with Speedlights such as SB-800, 28, 27, and 22S
4) Range-priority manual flash; available with SB-800
Flash Sync Mode
1) Front-curtain Sync (normal) 2) Red-eye Reduction 3) Red-eye Reduction with Slow Sync 4) Slow Sync 5) Rear-curtain Sync
Built-in Speedlight
Manual pop-up with button release
Guide number
(ISO 200, m): approx. 17 (manual 18)
(ISO 100 equivalent, m): approx. 12 (manual 13)
Flash Compensation
-3 to +1 EV in increments of 1/3, 1/2 or 1 EV
Accessory Shoe
ISO 518 Standard hot-shoe contact with safety lock provided
Sync Terminal
ISO 519 standard terminal
Creative Lighting System
With Speedlights such as SB-800, SB-600, SB-400, SB-R200, supports Advanced Wireless Lighting, Auto FP High-Speed Sync, Flash Color Information Communication, modeling flash and FV lock
Self-timer
2 to 20 seconds duration
Depth of Field Preview
When CPU lens is attached, lens aperture can be stopped down to value selected by user (A and M mode) or value selected by camera (P and S mode)
Remote Control
Via 10-pin terminal or Wireless Transmitter WT-4 (optional)
GPS
NMEA 0183 (Ver. 2.01 and 3.01) interface standard supported with 9-pin D-sub cable (optional) and GPS Cable MC-35 (optional)
Supported Languages
Chinese (Simplified and Traditional), Dutch, English, Finnish, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Swedish
Power Source
One Rechargeable Li-ion Battery EN-EL3e, Multi-Power Battery Pack MB-D10 (optional) with one Rechargeable Li-ion Battery EN-EL4a, EN-EL4 or EN-EL3e or eight R6/AA-size alkaline (LR6), Ni-MH (HR6), lithium (FR6) batteries, or nickel-manganese ZR6 batteries, AC Adapter EH-5a (optional)
Tripod Socket
1/4 in. (ISO 1222)
Custom Settings
48 settings available
Dimensions (W x H x D)
Approx. 147 x 114 x 74 mm (5.8 x 4.5 x 2.9 in.)
Weight
Approx. 825 g (1.82 lbs.) without battery, memory card, body cap, or monitor cover
